Applies to RouterOS:v3, v4

  • 4Creating a Metarouter
  • 5OpenWRT as virtual machine
  • 9Configuration examples
  • 10Reference
  • 11Known Issues
    • 11.1MIPS-BE
    • 11.2PPC

Overview

MetaRouter is a new feature in RouterOS 4.0 beta 1 and RouterOS v3.21

Currently MetaRouter can be used on

  • RB400, RB700 series except models with SPI flash, RB900 series except models with SPI flash, RB2011 boards
  • Listed PPC boards: RB1000, RB1100, RB1100AH and RB800.

Upgrading OpenWRT on Mikrotik Routerboard Hello, I already posted before but I deleted that thread because now I need something else. I have a Mikrotik RB433AH hardware which has the unstable version of Chaos Calmer installed on it. Lede-XX.XX.X-ar71xx-mikrotik-vmlinux-initramfs-lzma.elf file you need to upload to the source device, this file is used to run in MikroTik memory. How the installation proceeds (elucidation) OpenWrt installation takes place in two stages - first we write OpenWrt to the device's memory, then install image to the target device NAND. Mikrotik Routerboard Winbox. Chillifire Hotspot Router Installation Guide – Mikrotik Routerboard Version 12.09. Based on OpenWrt) to run this firmware on a virtual server using Mikrotik's. Routers: What is the advantage of. X86 hardware or on MikroTik's own 'RouterBoard' hardware which. 3G/4G data cards similar to OpenWRT/DD-WRT.

Requirements

Each Metarouter instance uses the same amount of resources as a stand-alone RouterOS installation. It means that you need a minimum of 24MB of RAM for each RouterOS virtual machine plus memory for the MetaROUTER host itself. It is suggested to have more than 24MB memory available for each Metarouter. Upcoming RouterOS versions will have ability to run virtual machines with less than 16MB per machine.

Note:It is possible to run other virtual machines with less than 24MB RAM per machine if the virtual operating system is OpenWRT. The 24MB limitation is only for virtual RouterOS installations.


Currently on one host you can create up to 8 virtual machines and up to 8 virtual interfaces. Workaround to have more than 8 interfaces in total is to use VLANs. In future versions it will be possible to add up to 16 virtual machines.

Also it is not possible to use external storage devices (Store) in the metarouter virtual devices.

Where it can be used?

The MetaRouter function is useful for allowing clients or lower-privilege users access to their own 'router' and config to configure as they like, without the need for a complete second router, or giving them access to the main router configuration.

For example; a WISP can create a virtual router for the clients ethernet port allowing them to define their own firewall settings, while leaving the WISP's wireless settings untouched.

Creating a Metarouter

As you can see, creating virtual router is quite easy, you just have to specify name of the router, how much RAM will be allocated for it and disk size that will be used by virtual router. Explanations of all other properties are available in reference manual.

Note: * be careful when using dynamic HDD size for metarouters, a proxy could fill up all your hosts storage!

Example with no settings

If you will add a new metarouter without specifying any parameters, it will be added with Dynamic HDD size, and 16MiB of RAM:

OpenWRT as virtual machine

Starting from v3.24 and v4.0beta3 MetaROUTER has the ability to import custom built images. As an example we will show how to patch and use OpenWRT as the virtual machine.

Importing image

If you don't have any specific needs, you can import our prebuilt OpenWRT image, which is downloadable MIPS image, PPC image. Upload openwrt image to the router and import it by import-image command:

As you can see OpenWRT is running, now you can start configuration process, which is explained in sections below.

Building your own OpenWRT image

If you are not satisfied with our prebuilt version of OpenWRT, then you can build and use your own image.

First step is to install svn and get the latest source code from openwrt.org

Note: Patch 1.2 was made against older kernel then in current trunk and some extra steps should be taken to apply it to OpenWRT. For example r29684 can be used without modifications


Now you have to patch downloaded source with our patch

Note: Patch v1.2 adds newer kernel support which makes it possible to compile with latest OpenWRT revisions. This patch also adds PowerPC support (ability to run OpenWRT image on RB1000 and RB1100).


When source is patched, you have to set up configuration options

Go to Target System menu and choose Mikrotik MetaROUTER MIPS or Mikrotik MetaROUTER PowerPC from the list depending for which platform you are building the image.

Other options depends on what is your requirements (include for example IPv6 and ppp support or not), you can also stick with defaults.


If you see any error messages while trying to launch menuconfig, like

It means that required libraries are not installed, check the output and install all required libraries.

OpenWrt

When you are done with build configuration, type

It will take a while to build everything so you can go and have a cup of tea.

After the build process is done, upload newly built image to the router and import it as described in section above.


Warning: On newer GCC versions you may be required to add this patch from OpenWRT [1]


For more options and build instructions look in OpenWRT's documentation

Adding Interfaces

Mikrotik Routerboard Rb2011il In

First, you need to add a new interface to your virtual router. This is done in the interface menu.

The interface command has the following options:

Description of each option can be found in reference manual.

Let's add one interface:

On the host physical router the interface appears as a virtual interface:

Connecting to the virtual machine

To connect to your virtual machine, use the console command:

You will see your newly added virtual interface here:

To disconnect from the metarouter virtual machine console, hit CTRL + A and then Q to Quit back to your Host console (if you are using minicom, hit CTRL + A twice):

Configuring a virtual network

Right now you saw that the virtual interface is visible in the HostInterfaces menu as vif1 and also in the metarouter interfaces menu as ether1. You can add an IP address on both interfaces, and set up networking. Creating a bridge between the virtual interface and a physical interface allows traffic to pass.

Configuration examples

Creating isolated Metarouter for client

This Example will show how to use Metarouter feature to create a isolated router on top of the WISP client site router. The setup for the example is shown on the diagram below:

Installing OpenWrt On A Microtik Routerboard RB433 - Ixs ...

1. Adding a Metarouter for client:

2. Adding Metarouter Interfaces for the new created Metarouter:

Mikrotik Routerboard Configuration

3. Creating a Bridge Interface for bridging metarouter interface together with ethernet interface where the client is physically connected:

4. Adding IP configuration for the new Metarouter interface which will be used for connecting between Metarouter and Metarouter Host system:

5. Connecting to Metarouter using the Console

6. Configuring Metarouter to make it easy for client to understand the configuration:

Reference

General

Sub-menu:/metarouter

Menu specific commands:

PropertyDescription
console(console <vm-id>)connect to specified virtual machine's console
import-image(import-image file-name=<image-file>)import custom built image (available starting from v3.24 and v4.0b3)
reboot(reboot <vm-id>)reboot specified virtual machine
shut-down(shut-down <vm-id>)shut down specified virtual machine
start(start <vm-id>)boot up specified virtual machine

Configurable properties:

PropertyDescription
disk-size(unlimited|0..4294967295[kiB] ; Default: unlimited)Disk size that will be allocated by virtual router.
memory-size(16..256[MiB] ; Default: 16)Amount of memory that will be allocated by virtual router.
name(string ;)Name of the virtual machine.


Read only properties:

PropertyDescription
used-disk(integer[kiB] ;)currently used disk space by virtual router.
disk-reads(integer;)number of disk reads
disk-writes(integer;)number of disk writes
state(booting|running|rebooting|shutting-down|stopped|disabled;)current state of virtual machine

Interface

Sub-menu:/metarouter interface

Configurable properties:

Mikrotik routerboard rb2011See full list on blog.poettner.de
PropertyDescription
dynamic-bridge(string;)If set, dynamic interface will be automatically added as port to specified bridge interface.
dynamic-mac-address(mac;)mac address of dynamically created interface
static-interface(none|name-of-iface;)Assign physical interface on the router to static virtual interface. This binds physical interface of the host directly to the guest instance.
type(dynamic|static;)Set if interface is either static or dynamic.
  • dynamic interface will add virtual-ethernet automatically when virtual machine starts.
  • static interface have to have created virtual-ethernet interface at the time of creation of the entry.
Dynamic interface names cannot be altered by the user. It is possible to add new virtual interface via '/interface virtual-ethernet' menu if custom name is desired
virtual-machine(string;)specifies to which virtual machine this interface will be bound
vm-mac-address(mac;)interface mac address that appears in VM

Known Issues

MIPS-BE

Issues and possible workarounds for MetaROUTER feature on RouterBOARDs with MIPS-BE architecture

Random freezing

Issue has been resolved in RouterOS 6.x

PPC

Issues and possible workarounds for MetaROUTER feature on RouterBOARDs with PPC architecture

Not enough resources

Only listed routers are affected: RB1100AH

When attempt is made to create MetaROUTER guest on the router error message is given that there is not enough resources on the router to create guest.

This problem is resolved in 5.12 and later RouterOS releases. If you are using a newer release and still encounter the problem on the router you have to reinstall the router using Netinstall tool.

RouterBOARD RB1100AHx2 reports similar message, but MetaROUTER feature is not currently supported on this router.

All other routers form this architecture that support MetaROUTER feature are not affected.

Other issues that do not fit the description most probably are caused by RouterOS misconfiguration and do not have a common denominator and have to be checked case by case.

Retrieved from 'https://wiki.mikrotik.com/index.php?title=Manual:Metarouter&oldid=33468'
17 de Janeiro de 2015, 9:06 - 0sem comentários ainda| Ninguém está seguindo este artigo ainda.

Proprietary stuff, what a bad choice! RouterOS has many features and SXT has pretty powerful hardware, but with level 3 licence you can't even work as a AP! Shame on you Mikrotik!

Start by installing some tools on your machine to setup a TFTP and DHCP server:

sudo apt-get install isc-dhcp-server atftpd wireshark

Write to /etc/default/atftpd

And to /etc/dhcp/dhcpd.conf

Then

The manual is at http://i.mt.lv/routerboard/files/SXTug.pdf. There you have a Button Index where you can see that if you hold the Reset button for more than 20 seconds (10 seconds after blinking stops) then Etherboot will be triggered.

Do this while watching Wireshark and /var/log/syslog

If things has gone correctly, you should be able to access the Luci web interface at http://192.168.1.1

Now you'll need a local webserver for wget2nand to download the kernel and the rootfs:

Now flash!

If you want to flash multiple devices, setup one with the packages (I've installed rsync ppp-mod-pptp luci-app-qos) and configuration you want and package a new rootfs (replace IP of the template device):
